The 8 ports PoE Ethernet Switch with 8 downlink PoE ports and double 1000Mbps uplink ports is a security surveillance Ethernet Switch which is applicated in high definition network surveillance and security system. The product fully combines the characteristics of security surveillance,Besides, the 8 downlink PoE ports support IEEE802.3af/at standard,  The ESD, 6KV lightning protection and surge protection circuits improve product stability. Also the device supports one key CCTV mode which realizes VLAN function, restrains the network storm, protects the information security, prevents the virus spread and cyber attack, fully satisfies the Ethernet video security surveillance system and Ethernet projects needs.

Advantage

√ Main Function: Provide 8*10/100Base-T Ethernet ports(PoE) , 2*10/100/1000Base-T uplink Ethernet ports.

√ Compliance with standards: IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x, IEEE802.3af/at.

√ PoE Power Display: 8 ports support LED display PoE working status. whole machine reaches 110W PoE power output.

√ One-key Smart: Support three kinds of working modes (Default, VLAN, CCTV).

√ Protection: Support  6KV surge immunity, EFT testing standard.

√ Operation Environment: Support -10℃~50℃ wide-temperature.

This is a 2000VA/1200W Line Interactive UPS With Automatic Voltage Requlation, 4X IEC C13 Outlets with USB Port. This UPS is ideal for protecting PC,workstation, NAS, Internet access point,TV,Point of sale and business telephony.

UPS is securing your data and your equipment by protecting you against power outages and bad power quality. It work through under and over voltage without wasting battery thanks to Automatic Voltage Requlation (AVR). Its Power Management Software is called Eaton UPS Companion software which use one communication port- USB port. ( The software is available on www.eaton.eu/powerquality)

Manufacturer of this UPS, EATON they are the leading manufacturer with decades of experience and high quality standard: CE compliance certified by external agency (TUV)

This UPS has an Automatic integration into Windows/MacOS/Linux power management for safe system shutdown. It also analyze energy use and costs,manage parameters,with Eaton UPS Companion software.

Input Voltage of 170-280V, Nominal Voltage 230V.

Batteries: Typical backup times for 1 PC- 50Minutes, Typical backup times for 2 PC is 26 Minutes, Typical backup times for 3PC is 10 Minutes and Typical backup times for 4 PC is 5 Minutes.

This UPS has a dimension of 330 X 180 X 133mm , Weight of 10.6 kg and a warranty 2 years.
